computing chips in AV

chips requirements in vehicle

Bosch :
Bosch

BMW:
BMW

the next-generation vehicle EE platform can be easily modulized based on the topology of network composed by domain controllers and in-vehicle Ethernets. take an example with Singulato iS6, which has five domains: smart driving, powertrain, chassis, smart body, smart seat.

each domain need support by a domain controller unit(DCU), the core of which is a powerful computing chip, which is usually more powerful than traditional ECUs. in average, L2 requires computing power about 10TOPS , L3 needs 60TOPS, L4 needs 100TOPS.

computing chips

product MDC600 Driver PX Pegasus EyeQ 4 BlueBox R-car H3 Journey2.0
Huawei Nvidia Mobileye NXP Renesas Horizon
TOPS 352 320 2.5 10
main cores 8 * 晟腾310 16 ARM VMP LS2084A 4*Arm/A57 BPU2.0
other cores Ascend 310 2 TensorCore GPU S32V234 4*Arm/A53 FPGA
AV-level L3+ L5 L3 L4(target) IVI L3
Camera support 16 10 8 8 8 4
Lidar support 8 6
function safety ASIL-D ASIL-B ASIL-D ASIL-D(target) ASIL-B ASIL-B

R-car H3

products timeline

Tier1s/Tier2s timeline

2018 2019 2020 2021
Aptive level3 level4
Bosch level2 level3 level4
Conti level2 level3+
Autoliv level2 level3 level4
Intel level3 level4+
Nvidia level3 level4+

Chinese OEMs timeline

2019 2020 2021 2022+
changan level4
FAW level4
GAC level3 level5
Geely level3 level5
GWM level3 level4
SAIC level3
xiaoPeng level3
WeiMa level3
Nio level2 level4+

global OEMs timeline

2018 2019 2020 2021 2022+
Ford level2 level4
GM level2 level4
Fiat-Crysler level3+
Audi level2 level4
Mercedze level2 level3 level4
Toyota level2 level3 level4
Honda level3 level4
